WiBOX PA M0407-8X is a MIMO 2x2 patch panel antenna dedicated to TV White Space operating at the frequency: 470-700 MHz with 8 dBi gain. The antenna is predicted to be used outdoor, it works in X (slant) polarization. It´s wide beams makes it ideal solution for mobile installations as the client antenna. The aerial can be used e.g. for TV transmission (or any system operating on this band). The antenna is integrated with the top quality WiBOX Large box system and comes with No. 2 of N Female connectors located on the bottom of the enclosure.
Big and voluminous BOX in WiBOX systems enables the possibility to instal different radio equipment inside.
Every WiBOX systems are predicted to use outdoor, they are made of UV resistant ABS plastic material, which is also resistant for bad weather conditions like rain, snow, humidity. Special designed sealing systems guarantees IP67 waterproof level. WiBOX systems can work in any weather conditions, temperature range is from -40°C up to 80°C.
Comprehensiveness of WiBOX system installation, WiBOX system can be installed using WiMount mounting system on a pole mast or a wall.
WiBOX system has certified IP67 waterproof level. It predicts the system to be used in any outdoor applications on the mast or on a wall. WiBOX system is equipped with top quality RJ45 waterproof system or with standard fee-thru unit to install Ethernet cable to the WiBOX, keeping the waterproof performances.
WiBOX system is desired for building systems composed of few antenna systems. To realize this possibility, there are No. 4 of additional holes for another antenna connectors.
WiMount bracket is designed to connect stability and attractive shape in one product. This aesthetic design is made of a special fiberglass reinforced plastic, which is rigid even in extremely weather conditions. Innovative shape and the plastic instead of metal bracket, offers better performances and no rust during all life-time. WiMount enables the antenna position aligning in two polarizations.
